Piezometer with Digital Water Level Recorder (DWLR)
READY STOCK AVAILABLE FOR DETAILS CONTACT +91-8505000822
Output : RS-485 / Analog 4-20 mA or Customization
Maximum Range : Up to 400 meters
Storage : Upto 32 GB
Accuracy : ±0.5% of Full Scale Output (FSO)
Housing Material : SS
Cable Material : PTFE
Temperature : -20 to 85’C
1-year full replacement guarantee(except physical damage and theft)
We are leading manufacturers of Rajasthan offer high-quality piezometers ideal for environmental monitoring. Discover the best piezometer with Digital Water Level Recorder (DWLR) based CGWA norms for groundwater monitoring. In affordable prices, advanced models with wireless telemetry for water level recording. Perfect DWLR piezometer to suit your needs and budget.
**Specifications and pricing may vary based on your specific needs and requirements.
| Model | VIFLOW-DWLR |
| Measuring Range | 0 – [400] m (Customizable as per requirement) |
| Resolution | 0.1 mm |
| Sensor Type | Piezoelectric |
| Material | Stainless Steel (SS316) |
| Power Supply | 12vDC |
| Data Logger | Integrated Digital Water Level Recorder (DWLR) with Real-Time Clock |
| Memory Capacity | Up to 32 GB (Expandable) |
| Communication | GSM / GPRS |
| Ingress Protection | IP67 / IP68 |
| Operating Temperature | -20°C to +85°C |
| Installation Method | Borewell / Open Well / Tank Application |
| Display | LCD for Real-Time Data Visualization |
| Software | Cloud-Based Data Logging & Analysis |
| Certification | ISO 9001:2015, CE Certified |
| Memory Technology | SD Card |
| Applications | Groundwater Monitoring, Reservoirs, Open Wells, Rainwater Harvesting Structures, etc. |
| Optional Features | Power Operated if Needed |
| Display | Digital |
The Water Level Monitoring Piezometer measures the groundwater level and DWLR records the data. Data can be display through a memory card or USB pen drive. So we can also display the data on our PC or Mobile through GSM. But It is mainly use for measuring the water level of bore wells & rivers.
Piezometer:
A piezometer for groundwater is a device used to measure groundwater pressure at a particular point. Because it consists of a perforated pipe or casing installed into the ground at a desired depth. The electric piezometer tip is usually open or covered with a porous material because it allows water to enter the pipe while preventing soil particles from clogging it. The water level inside the piezometer rises and falls with changes in the groundwater level.
Digital Water Level Recorder (DWLR): The DWLR is a digital device equipped with sensors and data logging capabilities to accurately measure and record the water level at the piezometer. It includes a pressure sensor or other technology to detect the water level changes. Because the DWLR can store data internally and may also have the capability to transmit data wireless to a central database or monitoring station.
Features :
- Waterproof stainless steel sensor.
- Compact size, Easy to install & also easy to Transport.
- No maintenance is require.
- Pressure Transducer not affected by Wind or Rain.
- Monitor the Level of groundwater and rivers.
- 4-20mA current output.
- Display the data on screen & also store it in excel format.
- High accuracy, reliability & Precise.
- Rust-proof & also corrosion-resistant.
- Shielded wire.
Guidelines for CCGWA-based Piezometer and DWLR.
Vision World Tech Pvt Ltd Provides Services Related to CGWA are:
